PRODUCT DETAILS



Number of views:
1005

Poultry dipping wax pool

Retail price
0.0
Market price
0.0
 Poultry dipping wax pool is a wax melting equipment designed and produced by our company for various types of meat duck and goose processing.The Poultry dipping wax pool completely replaces artificial wax dipping and combines the functions of melting wax and wax dipping.It has the advantages of stable performance, convenient use, cleaning, and energy saving. It is very suitable for small fluff removal in the slaughtering process of meat ducks and goose.
Product serial number
Quantity
-
+
Stock:

TEL: +86-536-6428777

MOB:+86-13964727777

FAX:0536-6184818

EMAIL: haozejixie@163.com

ADD:Zhucheng economic development zone,

1
Product description
Parameters
英文:
duck wax dipped poultry pool
1. Equipment overview
   Poultry dipping wax pool is a wax melting equipment designed and produced by our company for various types of meat duck and goose processing.The Poultry dipping wax pool completely replaces artificial wax dipping and combines the functions of melting wax and wax dipping.It has the advantages of stable performance, convenient use, cleaning, and energy saving. It is very suitable for small fluff removal in the slaughtering process of meat ducks and goose.

Item Name

duck geese wax dipped poultry pool

Item Size

HZ-JL-30

Capacity

1500-3000kgs /H

Overall Size

L*1100*1050mm

Temperature

67-73

Specified Voltage

380V or Customized

Material

Stainless steel 304

2.Basic structure and working principle
   The dipping wax pool is mainly composed of a pool body, a thermal insulation layer, a wax melting section, a wax dipping section, and a heating sleeve, and is divided into two types of stainless steel and ordinary materials.
   This equipment melts the wax in the wax melting pool part through the heating sleeve (heating medium is high-temperature steam). The melted wax enters the wax dipping pool part through the window on the middle partition wall, and the wax dipping operation can be performed.
3.Using method
  *1. First put the wax prepared in a certain proportion into the melting wax tank section, and open the steam valve of the external heating tube of the melting wax section and the wax dipping section at the same time.(Before the wax is put in, the user should add an appropriate amount of water, and it is advisable to just run over the heating pipe).
  *2. When the liquid level between the melted wax part and the wax impregnated part reaches equilibrium (that is, the liquid levels on both sides just reach the lower edge of the small window), stop putting wax.
  *3. Adjust the steam valve of the outer heating tube of the impregnated wax part to control the temperature between 67-73 ℃, and then perform the impregnated wax work.
  *4. The heating tube is mainly divided into the internal heating tube and the external heating tube. When you continue to use it for a long time, you must first turn on the internal heating to melt the wax in the external heating tube, and then open the external heating tube valve. The valve of the inner heating tube does not need to be opened during normal use.
  *5. In order to prevent wax backflow, an air return valve must be installed on the steam pipeline during the installation. When end the work, the wax pool heating valve is closed and then the boiler main valve is closed before the air return valve is opened. For the same reason, when returning to work, you must first close the air return valve and then open the main valve and the heating valve.
  *6. Remove the small fluff from the wax dipping pool after the shift every day to ensure the normal work of the next shift.
structure features:
1 When used to remove ducks remaining spots of melting wax, wax dipped.
2 the use of steam heating equipment.
3 Interval part melts the wax and wax-impregnated with insulating layer, the whole outer insulation layer of insulation.

Keyword:
dipping wax pool
